Product Overview
Katool USA Full Rise Scissor Lift KT‑X95 is a flush-mount full rise scissor lift engineered to deliver powerful lifting performance and reliable operation for automotive maintenance, diagnostics, and repairs. With an 8,000 lb (3,500 kg) capacity and a full height rise of 72.3 in, this lift gives technicians comfortable access to the vehicle underbody while preserving workspace when lowered. CE certified and tested beyond industry standards, it’s built to perform in professional environments.
Whether you’re servicing cars, SUVs, or light trucks, the KT-X95 combines robust construction with advanced safety systems — including pneumatic lock release, 24 V control system, and height limit protections — making it a great choice for busy shops and serious DIYers.
Key Features
-
8,000 lb (3,500 kg) max lifting capacity — handles most cars, SUVs, and light trucks with ease.
-
72.3″ full rise height — gives excellent undercarriage access for detailed work.
-
Flush-mount design — minimizes trip hazards and preserves workspace when not in use.
-
Pneumatic safety lock release — reliable locking with compressed air control.
-
24 V safe control system & height limit switch — enhanced operator safety.
-
Composite rubber lifting blocks included — secure contact points protect vehicle surfaces.
-
Drive-up ramp lock design — extended runways for longer wheelbases.
-
Aluminum motor with cooling fan — prevents overheating during extended cycles.
-
Self-lubricating bushings and bearings — smoother operation and lower maintenance.
-
CE Certified — tested to 115 % dynamic and 150 % static load standards.
| Specification |
Details |
| Model |
KT-X95 |
| Lifting Capacity |
8,000 lbs (3,500 kg) |
| Max Lifting Height |
72.3″ (1,836 mm) |
| Lifting Time |
≤ 50 seconds |
| Platform Length |
58.9″ (1,496 mm) |
| Platform Width |
24.4″ (620 mm) |
| Motor Power |
2.2 kW |
| Rated Oil Pressure |
20 MPa |
| Air Pressure Requirement |
6–8 kgf/cm² (≈ 85–115 psi) |
| Control Voltage |
24 V safe control |
| Safety Features |
Height limit switch, pneumatic lock system |
| Design |
Flush-mount, drive-up ramps with lock |
| Certifications |
CE (115 % dynamic / 150 % static tested) |
| Equipment Included |
Lifting blocks, control system |
| Installation Requirements |
Concrete anchoring not required |
Why Choose It?
The KT-X95 offers full rise performance without bulky posts, making it perfect for shops that value clean floor space and unobstructed access. With strong safety systems and robust hydraulic design, this lift supports both everyday service tasks and heavy-duty maintenance with confidence.
